BOSCH 1928498061
概述
Product information
| part designation (long form) | terminal |
| part number | 1 928 498 061 |
| offer drawing | C 928 002 37A |
| technical customer documentation | Y 928 K03 002 |
| processing specification | Y 928 V03 002 |
Technical information
| packing unit | 4000 pc. |
| minimum order quantity | 4000 pc. |
| time of delivery | on request |
| terminal type | box-contact |
| raster unit | 5 mm |
| secondary locking | locking plate |
| type of locking mechanism (terminals) | by locking beams |
| row distance | 5 mm |
| temperature range, from | -40 °C |
| temperature range, till | +130 °C |
| terminal surface | tin-plated |
| wire cross section | 1.5 - 2.5 mm² |
| seal of wire | single wire seal |
| line voltage from | 20 mV (DC) |
| line voltage to | 40 V (DC) |
| current-carrying capacity | max. 14 A |
